Standard Closed Cell Backer Rod
The Standard Closed Cell Backer Rod is a versatile and essential component for construction and joint sealing projects. Made from durable, closed-cell, low-density polyethylene foam with a density of 1.5 lbs/cu. ft. and an R-value of 2.2, this backer rod is designed to provide a flexible, compressible, and non-absorbent backing for joints. Its primary function is to control the depth of sealant, ensuring proper application and maximizing the longevity of your seals.
With its skin-like outer texture, the Standard Closed Cell Backer Rod offers superior bonding with a wide range of cold-applied sealants, including butyl, polysulfide, acrylic, polyurethane, and silicone. This makes it ideal for applications such as glazing operations, window and door installations, expansion joints, curtain wall joints, and partitions. It is also highly effective in log construction and pavement joints, where precise joint control is critical.
The rod’s dark grey color ensures a professional appearance in exposed installations, while its compressibility and lightweight design allow for easy handling and installation. It serves as a temporary joint seal and a backstop for tooling, promoting even application of sealants. This product meets several ASTM standards, ensuring reliability and performance in demanding conditions.
Features
- Made from durable, closed-cell, low-density polyethylene foam.
- Density of 1.5 lbs/cu. ft. and R-value of 2.2.
- Flexible and compressible for easy installation.
- Non-absorbent design prevents moisture retention.
- Compatible with various sealants, including silicone, polyurethane, and acrylic.
- Skin-like texture enhances bonding with sealants.
- Provides consistent sealant depth control for optimal application.
- Ideal for glazing, expansion joints, and window and door installations.
- Suitable for log construction and pavement joint projects.
- Acts as a temporary joint seal and backstop for sealant tooling.
- Lightweight and easy to handle on job sites.
- Dark grey color for a professional finish in exposed applications.
- Conforms to ASTM standards for reliability and performance.
- Available in various sizes to suit specific project requirements.
- Made in Canada.
Standard Closed Cell Backer Rod Specifications
| Diameter | Box contents | Length Per Box |
|---|---|---|
| 1/4 in. | 4000' Roll - Box of 1 | 4000 ft/box |
| 3/8 in. | 2100' Roll - Box of 1 | 2100 ft/box |
| 1/2 in. | 2500' Roll - Box of 1 | 2500 ft/box |
| 5/8 in. | 1550' Roll - Box of 1 | 1550 ft/box |
| 3/4 in. | 1100' Roll - Box of 1 | 1100 ft/box |
| 1 in. | 600' Roll - Box of 1 | 600 ft/box |
| 1 1/4 in. | 400' Roll - Box of 1 | 400 ft/box |
| 1 1/2 in. | 420' Roll - Box of 1 | 420 ft/box |
| 2 in. | 6' Rolls - Box of 42 | 252 ft/box |
| 2 1/2 in. | 6' Rolls - Box of 27 | 162 ft/box |
| 4 in. | 6' Rolls - Box of 9 | 54 ft/box |
| 5 in. | N/A | 90 ft/box (Available by custom order) |
| Custom | N/A | Contact CustomerService@CMUSupply.com for custom sizes |
