Imer Mix 200 FP Portable Vertical Shaft Paddle Mixer

SKU: 266441

| MPN: 1195163

IN STOCK (0)

Brand

Imer Mix 200 FP Portable Vertical Shaft Paddle Mixer

The Imer Mix 200 FP Portable Vertical Shaft Paddle Mixer is a powerful and efficient tool designed for construction professionals who require reliable mixing capabilities. With a generous 200L drum capacity, this planetary mixer is ideal for mixing premixed bagged materials and traditional mortars. Its compact design and road tires provide excellent maneuverability, making it easy to move around construction sites. This mixer ensures high performance and convenience, perfect for heavy-duty use.

One of the standout features of the Mix 200 FP is the I-DUST dust control grid, which helps to limit dust emissions and maintain a cleaner work environment. This feature is especially beneficial for indoor projects or sites where dust management is crucial. The adjustable mixing paddles allow users to modify the height up to 18 mm for optimal mixing results, while the oscillating discharge outlet helps to prevent clogging and facilitate efficient cleaning.

Designed with simplicity and user-friendliness in mind, the Mix 200 FP includes adjustable leg heights in three positions, making loading and unloading more convenient. The reliable gearbox, derived from the proven MIX 120 Plus model, ensures consistent performance. The mixer also boasts an electric safety grate, a magnetothermic switch, and Valpa elastic closures for secure fastening, enhancing the safety and durability of the equipment. Pneumatic wheels and an independent elastic suspension provide stability and smooth mobility on uneven terrains.

Features

  • 200L drum capacity for large-scale mixing.
  • Comes with I-DUST Grate
  • Compact design with road tires for easy maneuverability on job sites.
  • I-DUST control grid minimizes dust emissions for a cleaner environment.
  • Adjustable mixing paddles up to 18 mm for efficient mixing.
  • Oscillating discharge outlet prevents clogging and aids in cleaning.
  • Adjustable leg height in three positions for easy loading and unloading.
  • Reliable gearbox derived from the MIX 120 Plus for consistent performance.
  • Electric safety grate for added protection during operation.
  • Magnetothermic switch with IP55 minimum voltage coil and IP67 plug for safety.
  • Pneumatic wheels with independent elastic suspension for stable movement.
  • Lifting hooks and forklift guides for secure transport and handling.
  • Valpa elastic closures for secure and easy fastening of the bonnet and hood.

Imer Mix 200 FP Portable Vertical Shaft Paddle Mixer Specifications

Specification Details
Drum Capacity 5 cu ft
Mixing Performance 2 Bags Fireproofing
Drum Diameter 32 in
Paddle Speed 32 rpm
Machine Weight 573 lbs
Wheel Dimensions 15 in
Engine/Motor Power 1.5 HP, 120V 60 Hz
Discharge Height 22/27/32 in
Loading Height 90 (86) in
Width (Boxed) 30 in (40 in)
Length (Boxed) 54 in (49 in)
Height (Boxed) 50 in (36 in)
