H&B X-Seal Anchor - Box of 175 Features
- Advanced Design: Next-generation veneer anchor with improved features over DW-10-X®.
- Code Compliance: Meets/exceeds Commonwealth of Massachusetts Building Code for air leakage and water penetration.
- Enhanced Performance: Pronged legs provide independent, positive anchorage without sheathing compression.
- Vapor Barrier Integrity: Moves pronged legs inwards to effectively seal the insulation/wallboard.
- Increased Compressive Strength: Rib-stiffened pronged legs oriented closer together increase strength by over 20%.
- Finish Options: Available in hot dip galvanized and Type 304 stainless steel for durability in various environments.
- Versatile Sizes: Leg lengths from ½” to 4-1/2” cater to different insulation and wallboard combinations.
- Additional Protection: Compatible with X-SEAL® Tape for extra defense against air and moisture infiltration.
H&B X-Seal Anchor - Box of 175 Specifications
| Sizes | Thickness/Gauge | Backup Type | Finishes/Materials | Minimum Air Space Requirement |
| 1/2" | 14 gauge | Metal Stud | Hot-Dip Galvanized | 1/2" |
| 3/4" | Type 304 - Stainless Steel | |||
| 1" | Type 316 - Stainless Steel (Special Order) | |||
| 1 1/2" | ||||
| 2" | ||||
| 2 1/2" | ||||
| 2 5/8" | ||||
| 3" | ||||
| 3 1/2" | ||||
| 4" |
NOTE: If you don't see a size or style that you are looking for please contact our customer service dept (CustomerService@CMUSupply.com) for price, availability and lead times.
IMPORTANT: Since each construction project is unique, the appropriate selection and use of any product contained herein must be determined by competent architects, engineers and other appropriate professionals who are familiar with the specific requirements of the project in question. This drawing and/or data sheet is the confidential and proprietary information of Hohmann & Barnard, Inc. and is not to be reproduced, copied or disclosed, in whole or in part, without the prior written consent of CMU Supply.
